Description
Overview
The LC1D80B7 is a TeSys D (TeSys Deca) contactor from Schneider Electric with three normally-open power poles and a 24 V AC 50/60 Hz control coil. Schneider rates it at 80 A in utilisation category AC-3 at up to 440 V, placing it in the upper part of the TeSys D frame range for direct-on-line motor switching. The unit photographed carries the TeSys and LC1D80 markings together with built-in auxiliary contact terminals marked 13-14 (NO) and 21-22 (NC).
Technical data
- Range: TeSys D (TeSys Deca)
- Poles: 3P (3 NO)
- Rated operational current (AC-3, up to 440 V): 80 A
- Control circuit voltage: 24 V AC 50/60 Hz
- Utilisation category: AC-3
- Auxiliary contacts (as marked on unit): 1 NO (13-14) + 1 NC (21-22)
Applications
Contactors of this class are used to switch three-phase motors in pumps, compressors, conveyors, HVAC plant and machine tools, and in motor-starter and control-panel builds where a low-voltage AC control circuit is preferred. They are commonly paired with a matching thermal or electronic overload relay.
Sourcing from BOLTON
BOLTON Technical Equipment Supplies sources and supplies this item against request for quotation for defence, aerospace, UAV/UAS, MRO and industrial programmes across the UAE, Saudi Arabia and Australia. Pricing, lead time and documentation requirements (for example certificate of conformity or manufacturer datasheets where applicable) are confirmed against your RFQ. Add this item to your RFQ basket to request a quotation.
