EPC-830U for Micro-ATX Motherboard, Dual 17.3″ LCD, 400 W ATX Power, Keyboard, Cooling Fan — BOLTON SKU 58834.
About the EPC-830U for Micro-ATX Motherboard Dual 17.3″
The EPC-830U is a dual-screen rugged portable industrial computer chassis. Being epc-830u compatible with micro-atx motherboard boards, it is supplied as an enclosure rather than a finished system: the buyer fits their own Micro ATX board, processor, memory and storage. Two 17.3-inch 1920 x 1080 displays are integrated, the intended arrangement being a main screen for the operating interface and a second screen for multi-view monitoring. An 82-key keyboard and touchpad fold into the case, and a carrying handle makes the unit transportable. The chassis accepts a CPU of up to 95 W, including Xeon-series parts, and provides space for two 2.5-inch drives. Power comes from a 400 W ATX supply. Expansion covers one half-size PCIe x16 card and one full-size PCIe x4 card, with an optional built-in sound card module offering balanced and unbalanced audio.
Key specifications
| Attribute | Value |
|---|---|
| Model | EPC-830U |
| Displays | Dual 17.3-inch LCD, 1920 x 1080 |
| Motherboard support | Micro ATX |
| CPU support | Up to 95 W, compatible with Xeon series |
| Storage | 2 x 2.5-inch drive bays |
| Power supply | 400 W ATX |
| Input devices | 82-key keyboard and touchpad |
| Expansion | 1 x PCIe x16 half-size; 1 x PCIe x4 full-size |
| Dimensions | 420 x 314 x 189 mm (excluding rubber and handle) |
| Weight | 10.5 kg |
Typical applications
The two-screen layout — one operating display, one monitoring display — suits deployable control and monitoring positions: ground control stations, mobile test benches, field engineering desks and portable recording or broadcast setups. Because the buyer supplies the Micro ATX board, the platform can be matched to whatever capture, interface or GPU cards a programme requires, using the half-size x16 and full-size x4 slots. The 400 W supply and 95 W CPU ceiling define the thermal and power envelope to design within.
Supplied by BOLTON Technical Equipment Supplies against request for quotation. Add this item to your RFQ basket to request pricing, lead time and documentation requirements (e.g. CoC, datasheets or test reports where applicable).
