S1AL SWITCH TOGGLE SPST 15A 125V — BOLTON SKU 53367.
About the S1AL Technical Component
The S1AL is a full-size toggle switch from NKK Switches’ S series of panel-mount toggles. It is a single-pole, single-throw (SPST) device with a simple on-off action, rated 15 A at 125 V AC as stated in the product designation. Distributor data for this part describes a sealed-construction toggle with a locking lever actuator and solder lug terminations, mounted through a single round panel cutout on a threaded bushing. NKK’s S-series toggles are medium-capacity power switching components built with heat-tolerant resin cases for high arc resistance, used where a robust, positively actuated manual switch is needed on control panels and equipment enclosures. The S series covers a number of closely related lever, bushing and termination variants, so the exact actuator style and hardware for your installation should be confirmed against your drawing or sample at the quotation stage.
Key specifications
| Type | Toggle switch, panel mount |
|---|---|
| Manufacturer | NKK Switches |
| Configuration | SPST, on-off |
| Rating | 15 A at 125 V AC (per designation) |
| Termination | Solder lug |
| Construction | Sealed toggle with locking lever (per distributor data) |
Typical applications
Panel-mount toggle switches of this class appear on control panels, test rigs, ground support equipment and industrial enclosures wherever a robust manual on-off control is required. Locking-lever versions guard against accidental actuation in transit or in vibration-prone installations.
Supplied by BOLTON Technical Equipment Supplies against request for quotation. Add this item to your RFQ basket to request pricing, lead time and documentation requirements (e.g. CoC, datasheets or test reports where applicable).
Browse more in Distribution Control.
