GEDORE SE 9×12 Rectangular Open-End Fitting, 9 mm — BOLTON SKU 57598.
About the GEDORE SE 9×12 Rectangular Open-End Fitt Rectangular
The GEDORE SE 9×12 rectangular connector is the interface on this open-end insert tool: a 9 x 12 mm rectangular spigot that locates into the head of a matching insert-tool torque wrench. The working end is a fixed open-end (spanner) jaw sized 9 mm across flats. In GEDORE’s numbering the SE prefix identifies the open-end insert form, the 9×12 figure states the rectangular mount dimensions rather than the jaw size, and the separately quoted 9 mm is the size across flats — the two figures are easily confused when ordering. Insert tools of this type allow one calibrated wrench to cover many fastener sizes and profiles: the wrench provides the torque measurement, the insert provides the fastener engagement. Because 9 x 12 mm is a widely used mount dimension, the insert is not tied to one wrench model, but the wrench head must accept the same 9 x 12 mm rectangular fitting.
Key specifications
| Brand | GEDORE |
|---|---|
| Insert type | Open-end (spanner) fitting |
| Series designation | SE |
| Insert mount | 9 x 12 mm rectangular |
| Jaw size | 9 mm across flats |
Typical applications
Open-end inserts are used where a socket cannot be passed over the fastener — tightening union nuts, cable glands and pipe couplings that sit part-way along a line. At 9 mm across flats this insert suits small unions and instrument fittings rather than heavy structural bolting. It is held in maintenance workshops and assembly cells wherever a documented, repeatable torque value has to be applied to a fastener that can only be reached from the side.
Supplied by BOLTON Technical Equipment Supplies against request for quotation. Add this item to your RFQ basket to request pricing, lead time and documentation requirements (e.g. CoC, datasheets or test reports where applicable).
Browse more in Pipe & Tube Fittings.
