Gland Cap Nut, Nickel, PG16, Brass — BOLTON SKU 59514.
About the Gland Cap Nut Nickel PG16 Brass
This part is the cap (dome) nut of a cable gland assembly, made in brass with a nickel-plated finish and threaded PG16. Catalogued as gland cap nut nickel ip68, it is the component tightened down over the sealing insert of a gland body: as the nut advances on the PG16 thread it compresses the seal onto the cable jacket, and that compression is what forms both the seal and the strain relief. PG (Panzergewinde) is the older conduit thread series still widely used on European-pattern glands, and a PG16 nut mates only with a PG16 gland body. Brass gives a stable, machinable body that withstands the crushing loads of repeated tightening, while nickel plating provides a harder and more corrosion-resistant outer surface than bare brass. Ingress protection ratings such as IP68 are a property of the complete assembled gland — body, seal and nut — fitted to a cable of the correct diameter, not of the nut on its own.
Key specifications
| Component | Cable gland cap (dome) nut |
|---|---|
| Thread | PG16 (PG / Panzergewinde conduit thread series) |
| Body material | Brass |
| Finish | Nickel plated |
| Function | Compresses the gland sealing insert onto the cable jacket |
Typical applications
PG16 cap nuts are ordered as replacement or make-up parts when building control panels, junction boxes and field enclosures, and when refurbishing existing glanded entries whose nuts have been lost or damaged. Nickel-plated brass is a common specification for indoor and sheltered outdoor industrial installations. Because the nut is the compressing element, fitting a sound one restores clamping force on the seal without disturbing the gland body already installed through the enclosure wall.
Supplied by BOLTON Technical Equipment Supplies against request for quotation. Add this item to your RFQ basket to request pricing, lead time and documentation requirements (e.g. CoC, datasheets or test reports where applicable).
