GHR-06V-S CONN PLUG 6 POS FEMALE CRIMP 1.25MM — BOLTON SKU 55595.
About the GHR-06V-S Connector
The GHR-06V-S is a connector housing from the JST GH series of disconnectable crimp-style connectors on a 1.25 mm contact pitch. This housing provides 6 positions in a single row and accepts JST GH crimp contacts terminated onto discrete wires, mating with the corresponding GH shrouded header on the printed circuit board. JST describes the series as having a secure lock mechanism with a large outer latch for positive lock, low insertion force contacts that mate with a positive tactile clicking sensation, and a structure that prevents contact deformation; the housings are also designed to prevent incorrect mating. JST publishes series ratings of 1 A AC/DC using AWG #26 wire, 50 V AC/DC and an operating temperature range of −40 °C to +105 °C. The GH catalogue lists the GHR housing material as PBT, natural (white). Crimp contacts and application tooling are ordered separately and should be specified at quotation.
Key specifications
| Type | Crimp-style connector housing (wire side) |
|---|---|
| Series | JST GH |
| Positions | 6 |
| Pitch | 1.25 mm |
| Rows | 1 |
| Current rating (series) | 1 A AC/DC (AWG #26) |
| Voltage rating (series) | 50 V AC/DC |
| Operating temperature (series) | −40 °C to +105 °C |
| Housing material | PBT, natural (white) — per JST GH catalogue |
Typical applications
Fine-pitch crimp connector systems such as the GH series are used for board-to-wire links in UAV electronics, cameras and gimbals, avionics modules and compact industrial devices. They are routinely consumed in electronics integration and repair work.
Supplied by BOLTON Technical Equipment Supplies against request for quotation. Add this item to your RFQ basket to request pricing, lead time and documentation requirements (e.g. CoC, datasheets or test reports where applicable).
