GAONENG GNB 3S 11.1V 4000mAh 50C LiPo Battery XT60 — BOLTON SKU 58193.
About the GAONENG GNB 3S 11.1V 4000mAh 50C
The GAONENG GNB 3S battery is a lithium-polymer pack of three cells in series, which is what produces the 11.1 V nominal figure in the designation — three cells at 3.7 V nominal each. Rated capacity is 4000 mAh, so the pack stores approximately 44 Wh. The 50C marking is the manufacturer’s continuous discharge rating stated as a multiple of capacity, equivalent to about 200 A at the rated 4 Ah. Termination is an XT60 connector, the mid-size member of the XT bullet-connector family and the usual fit for packs in this voltage and capacity band. Compared with the higher-voltage packs in the same range, a 3S pack delivers a given output power at proportionally higher current, so wiring gauge and connector losses matter more in the installation; against that, the lower bus voltage suits equipment whose input range stops short of 4S and above.
Key specifications
| Brand | GAONENG (GNB) |
|---|---|
| Chemistry | Lithium polymer (LiPo) |
| Cell configuration | 3S (three cells in series) |
| Nominal voltage | 11.1 V |
| Rated capacity | 4000 mAh |
| Stored energy | Approx. 44 Wh (calculated) |
| Continuous discharge rating | 50C (approx. 200 A at rated capacity) |
| Connector | XT60 |
Typical applications
3S packs of around 4000 mAh are used in light unmanned aircraft, small ground robots and camera or gimbal platforms, and as a portable 11 V supply for field electronics and test rigs. The XT60 termination makes the pack directly compatible with the large installed base of power distribution boards, chargers and adapter leads built around that connector. The relatively high capacity for a 3S pack favours endurance-led duty cycles rather than the short high-power bursts that the smaller, higher-C packs are built for.
Supplied by BOLTON Technical Equipment Supplies against request for quotation. Add this item to your RFQ basket to request pricing, lead time and documentation requirements (e.g. CoC, datasheets or test reports where applicable).
