My Scale LP7510 — BOLTON SKU 62193.
About the My Scale LP7510
This is a low-profile industrial platform scale with a 1.5 x 1.5 m weighing surface. The make my scale model lp7510 build is rated at 1 tonne capacity with a 500 g division, and is constructed in 304 grade stainless steel with an NTEP washdown fixed top, so it can be hosed down in wet-process, food or pharmaceutical areas without water tracking into the frame. The low-profile deck reduces the ramp gradient needed for pallet trucks, and the frame is designed for either pit installation flush with the floor or free-standing above-ground use. It is supplied with a T2 washdown indicator that switches between pounds and kilograms, offers a rechargeable battery option, and carries a built-in RS-232 port for connection to a printer, terminal or data-collection system; the indicator connects through a heavy-duty metal-shielded cable. The scale is factory calibrated and provides 200% overload protection.
Key specifications
| Attribute | Value |
|---|---|
| Model | LP7510 |
| Capacity | 1 tonne |
| Division | 500 g |
| Platform size | 1.5 x 1.5 m |
| Construction | 304 stainless steel, NTEP washdown fixed top |
| Installation | Pit or above-ground |
| Indicator | T2 washdown, lb/kg, rechargeable battery option |
| Data interface | Built-in RS-232 port |
| Calibration | Factory calibrated |
| Overload protection | 200% |
Typical applications
A washdown stainless platform of this size is used for goods-in and goods-out weighing of pallets, crates and drums in areas that are cleaned with water — cold stores, wash bays, food and pharmaceutical handling areas and chemical decanting stations. The RS-232 output lets weights be printed onto a docket or captured directly into a stock or dispatch system rather than transcribed by hand, and the battery option keeps the scale usable where a permanent socket is inconvenient.
Supplied by BOLTON Technical Equipment Supplies against request for quotation. Add this item to your RFQ basket to request pricing, lead time and documentation requirements (e.g. CoC, datasheets or test reports where applicable).
