Description
LiPo Rechargeable Battery 4000 mAh, 7.6 V, 2S — BOLTON SKU 53908.
About the LiPo Rechargeable Battery 4000 mAh 7.6
This battery lipo rechargeable 4000 mah pack is a two-cell lithium-polymer assembly with a nominal terminal voltage of 7.6 V. The 2S designation means two cells connected in series, and dividing the pack voltage by the cell count gives 3.8 V per cell — the nominal figure for high-voltage lithium-polymer chemistry rather than the 3.7 V of a conventional LiPo cell. That distinction matters in service, because a high-voltage pack has a higher fully charged voltage per cell than a standard LiPo and requires a charger set to the correct chemistry; charging it on a standard LiPo profile will not fill it, and the reverse error is hazardous. At 4.0 Ah and 7.6 V the pack stores approximately 30 Wh of energy. Lithium-polymer cells are subject to dangerous-goods rules in transport and require balance charging, temperature-controlled storage and storage at a partial state of charge.
Key specifications
| Attribute | Value |
|---|---|
| Chemistry | Lithium-polymer (LiPo), rechargeable |
| Capacity | 4000 mAh (4.0 Ah) |
| Nominal voltage | 7.6 V |
| Cell configuration | 2S (two cells in series) |
| Nominal cell voltage | 3.8 V per cell (high-voltage LiPo) |
| Nominal energy | Approx. 30 Wh |
Typical applications
A 2S 7.6 V pack at 4000 mAh is a payload and avionics power source rather than a main propulsion pack: powering ground-control and radio equipment, camera and gimbal payloads, handheld and portable instruments, small UAS airframes and test rigs. The high-voltage 3.8 V per cell chemistry is chosen where slightly more usable energy and a higher working voltage are wanted from the same physical two-cell footprint.
Supplied by BOLTON Technical Equipment Supplies against request for quotation. Add this item to your RFQ basket to request pricing, lead time and documentation requirements (e.g. CoC, datasheets or test reports where applicable).
Browse more in Uav Power Energy.
