222K132-25/225-0 Molded Part, Heat-Shrinkable, 90 deg Boot, Fluid Resistant Elastomeric, 150 °C, Fit Size 11 Backshell — BOLTON SKU 61693.
About the 222K132-25/225-0 Backshell
The 222K132-25/225-0 is a heat-shrinkable molded part from the TE Connectivity (Raychem) 222K family, supplied as a 90-degree right-angle lipped boot. Molded boots in this series are made from a fluid-resistant elastomeric material and are installed over the rear of a connector accessory, where they shrink down when heated to form a snug transition between the connector backshell and the cable bundle. Distributor listings for this part number describe it as an adhesive-lined right-angle lipped configuration, which bonds to the cable jacket as it recovers to improve sealing and strain relief. The product designation states a 150 °C temperature rating and a fit for a size 11 backshell. Boots of this type are used to protect wire terminations from fluids, abrasion and flexing at the connector-to-cable interface, and are a standard accessory in severe-environment harness construction.
Key specifications
| Type | Heat-shrinkable molded part, 90° right-angle lipped boot |
|---|---|
| Series | TE Connectivity (Raychem) 222K |
| Material | Fluid-resistant elastomer |
| Configuration | Adhesive-lined (per distributor listing) |
| Temperature rating | 150 °C (per product designation) |
| Fit | Size 11 backshell (per product designation) |
Typical applications
Connector boots of this type are used across aerospace and defence wire harnessing, UAV integration and vehicle electrical systems wherever a cable must exit a connector at 90° in a confined space. They are equally common in MRO workshops during harness repair and overhaul, where damaged boots are replaced to restore sealing and strain relief.
Supplied by BOLTON Technical Equipment Supplies against request for quotation. Add this item to your RFQ basket to request pricing, lead time and documentation requirements (e.g. CoC, datasheets or test reports where applicable).
Browse more in Backshells & Strain Relief.
