S30B0C-P09MCC0-5000 ODU Series B Push-Pull Straight Plug, 9-Pos, Solder — BOLTON SKU 55411.
About the S30B0C-P09MCC0-5000 ODU Series B Push-Pu Soldering
The designation S30B0C-P09MCC0-5000 identifies an ODU Series B circular connector in straight plug form, fitted with nine contact positions and solder-type terminations. Push-pull coupling means the plug is mated and unmated by axial movement of the outer sleeve: the latch engages on insertion and releases only when the sleeve is drawn back, so the joint is not undone by pulling on the cable alone. The straight body carries the cable in line with the connector axis rather than at an angle. Because the contacts are solder cups rather than crimp barrels, cable assembly is carried out with S30B0C-P09MCC0-5000 ODU Series soldering equipment — a temperature-controlled iron with a fine tip and suitable solder — instead of a crimp tool and positioner. Electrical ratings, shell material, keying and sealing class are not restated here; request the manufacturer datasheet with your enquiry so the exact variant is confirmed before order.
Key specifications
| Attribute | Value |
|---|---|
| Manufacturer designation | S30B0C-P09MCC0-5000 |
| Connector family | ODU Series B, push-pull |
| Body style | Straight plug |
| Contact positions | 9 |
| Termination | Solder |
| BOLTON SKU | 55411 |
Typical applications
Nine-way push-pull circular plugs of this type are used on instrumentation, sensor and control cable assemblies where an operator has to connect and disconnect frequently and often by feel. The solder termination suits low-volume builds, laboratory harnesses and repair work, where holding a crimp tool and positioner for every wire size is not practical. The straight body is the usual choice where the cable runs away from the equipment face without an immediate bend.
