Description
SkyRC Q200 Neo Charger — BOLTON SKU 53914.
About the SkyRC Q200 Neo Charger
The Q200neo is SkyRC’s four-port AC/DC balance charger. Each of the four outputs runs on an independent circuit, so packs of different chemistry and cell count can be processed at the same time. On AC the unit accepts 100 to 240 V and delivers up to 200 W in total; on DC it accepts 10 to 30 V and delivers up to 400 W in total, with up to 100 W available on a single port and a maximum of 10 A per port. Supported chemistries are LiPo, LiHV, LiFe and Li-ion up to 6S, NiMH and NiCd up to 15S and lead-acid up to 12S. Balancing is rated at 800 mA per cell with voltage equalisation accuracy of plus or minus 0.02 V. A 20 W USB-C port supporting PD 3.0 and QC 3.0 is included for charging ancillary devices.
Key specifications
| Type | Four-port AC/DC balance charger, independent circuits |
|---|---|
| AC input | 100-240 V |
| DC input | 10-30 V |
| Output power | Up to 200 W total on AC; up to 400 W total on DC (max 100 W per port) |
| Charge current | Up to 10 A per port |
| Chemistries | LiPo / LiHV / LiFe / Li-ion to 6S; NiMH / NiCd to 15S; Pb to 12S |
| Balance current | 800 mA per cell |
| Balance accuracy | plus or minus 0.02 V |
| USB output | USB-C, PD 3.0 / QC 3.0, 20 W |
Typical applications
Multi-port balance chargers are workshop and field equipment for UAV and ground-robotics operations, where several flight packs and transmitter packs must be cycled between sorties. The dual AC and DC input suits both a bench in a hangar or integration lab and a vehicle-powered setup in the field. Training and MRO facilities use them for routine battery maintenance and capacity checking.
Supplied by BOLTON Technical Equipment Supplies against request for quotation. Add this item to your RFQ basket to request pricing, lead time and documentation requirements (e.g. CoC, datasheets or test reports where applicable).
