Description
RF Cable Assembly, RG58, 10 m, RP-SMA Male to RP-SMA Female — BOLTON SKU 53250.
About the RF Cable Assembly, RG58, 10 m, RP-SMA
This RF Cable Assembly RG58 10 m long is terminated with a reverse-polarity SMA (RP-SMA) male connector at one end and an RP-SMA female connector at the other. RG58 is the long-established flexible coaxial cable type with a 50 ohm nominal characteristic impedance, used for general-purpose RF interconnection at moderate power and frequency. RP-SMA reverses the gender of the centre contact relative to standard SMA while keeping the same threaded coupling shell, and is the interface commonly fitted to Wi-Fi, telemetry and other licence-exempt radio equipment and their antennas. A male-to-female pairing makes this assembly an extension lead: it inserts between an existing RP-SMA antenna and its radio to relocate the antenna up to 10 m from the equipment. As with any RG58 run, attenuation increases with frequency, so higher-frequency links over this length should be budgeted accordingly in the link plan.
Key specifications
| Cable type | RG58 coaxial |
|---|---|
| Nominal impedance | 50 ohm |
| Length | 10 m |
| Connector, end A | RP-SMA male |
| Connector, end B | RP-SMA female |
| Configuration | Extension assembly (male to female) |
Typical applications
Assemblies like this relocate antennas away from radios and modems — moving a telemetry or Wi-Fi antenna to a mast, window or vehicle exterior while the equipment stays racked or sheltered. They also serve bench and range testing where an antenna must be positioned away from the unit under test.
Supplied by BOLTON Technical Equipment Supplies against request for quotation. Add this item to your RFQ basket to request pricing, lead time and documentation requirements (e.g. CoC, datasheets or test reports where applicable).
Browse more in Wire & Cable.
