Description
Weller WT 1010H WT 1H/WP 120/WSR201 230V (T0053438699N) — BOLTON SKU 67914.
About the T0053438699N Weller WT 1010H Station, 230
The T0053438699N WT 1010H soldering station is Weller item T0053438699N, supplied as a complete single-channel set: the WT 1H power unit, a WP 120 soldering iron and the WSR 201 safety rest. The power unit runs from 230 V at 50 Hz and is rated 150 W, with one channel and one switching output. Weller quotes an adjustable range of 50 to 550 degrees Celsius depending on the tool fitted, temperature stability of plus or minus 2 degrees Celsius and temperature accuracy of plus or minus 9 degrees Celsius. The station is ESD safe and provides equipotential bonding through a 3.5 mm jack socket on the front panel. It uses WT-series tips. The unit measures 150 x 130 x 101 mm and has a catalogue weight of 3.0 kg. Country of origin declared on supply is Mexico.
Key specifications
| Manufacturer part number | T0053438699N |
|---|---|
| Brand | Weller |
| Set contents | WT 1H power unit, WP 120 iron, WSR 201 safety rest |
| Supply voltage | 230 V, 50 Hz |
| Power unit rating | 150 W |
| Channels | 1 |
| Temperature range | 50 – 550 degrees C, tool dependent |
| Temperature stability / accuracy | +/- 2 degrees C / +/- 9 degrees C |
| Tip series | WT |
| Dimensions (L x W x H) | 150 x 130 x 101 mm |
| Weight | 3.0 kg |
| Country of origin | Mexico |
Typical applications
A single-channel 230 V station supplied complete with iron and safety rest is normally specified when standing up a new electronics bench, replacing an ageing station, or equipping a repair cell where each position needs one controlled iron rather than a multi-tool system. The stated temperature stability makes it appropriate where process control records temperature settings per job.
Supplied by BOLTON Technical Equipment Supplies against request for quotation. Add this item to your RFQ basket to request pricing, lead time and documentation requirements (e.g. CoC, datasheets or test reports where applicable).
