Metcal BVX-105 Fume Extractor — BOLTON SKU 55722.
About the Metcal BVX-105 Fume Extractor
The BVX-105 is a benchtop fume extraction system for a single soldering or rework position. It is supplied as a complete set: the BVX-100-series extraction unit, a positionable BVX extraction arm and the plenum hood that sits over the work, together with the filter set. On this variant the filter configuration is a pre-filter followed by two gas filters, which is the arrangement chosen when the extracted air is dominated by flux vapour and other gaseous by-products rather than by particulate. The unit accepts a 100 to 240 V ac supply and is self-contained, so neither ducting to outside the building nor a compressed-air supply is required. The BVX-100-series chassis is around 279 mm tall with a 305 x 229 mm plenum, so it can stand on the bench or be fitted underneath it using the optional mounting bracket. Filters are consumable and are replaced as a set of the same configuration.
Key specifications
| Type | Benchtop fume extraction system, single user |
|---|---|
| Series | Metcal BVX-100 |
| Filter set | Pre-filter + gas filter + gas filter |
| Supply voltage | 100 to 240 V ac |
| Supplied with | BVX extraction arm and plenum |
| Ducting | Not required — self-contained unit |
| Chassis height | Approx. 279 mm |
| Plenum size | Approx. 305 x 229 mm |
Typical applications
A single-position extractor of this type is placed at a hand-soldering, rework or conformal coating bench so that flux vapour is drawn away from the operator’s breathing zone at the point it is generated. The pre-/gas-/gas- filter set is selected where the dominant concern is gaseous flux and solvent vapour. Because the unit is self-contained and runs from a wide input-voltage range, it is practical for benches that are reconfigured or relocated, and for workshops where fixed ducting cannot be installed.
Supplied by BOLTON Technical Equipment Supplies against request for quotation. Add this item to your RFQ basket to request pricing, lead time and documentation requirements (e.g. CoC, datasheets or test reports where applicable).
