PT02E22-32P-150 Box Mounting Receptacle, Shell Size 22, 32 Pin Contacts — BOLTON SKU 56814.
About the PT02E22-32P-150 Box Mounting Receptacle, Connector
The PT02E22-32P-150 Box Mounting connector is a circular receptacle built on shell size 22 and fitted with a thirty-two contact insert in the pin configuration. A box-mounting receptacle is the fixed half of the pair: it is secured to the wall of an enclosure or junction box through its mounting flange, with the mating face presented outward for the plug and the terminations facing into the box for the internal wiring. Shell size 22 fixes the diameter of the shell and, with it, which insert arrangements can be fitted. Pin contacts mean this half carries the male contacts and the mating connector carries sockets, which is the point to check against the rest of the harness before ordering. Because the connector is a box-mounting type, the panel cut-out and fixing-hole pattern must be taken from the manufacturer drawing before the enclosure is machined. Coupling style, shell finish, contact termination and the meaning of the -150 modification code should all be confirmed against the manufacturer datasheet with your enquiry.
Key specifications
| Attribute | Value |
|---|---|
| Manufacturer designation | PT02E22-32P-150 |
| Connector type | Circular box-mounting receptacle |
| Shell size | 22 |
| Contacts | 32 |
| Contact gender | Pin |
| BOLTON SKU | 56814 |
Typical applications
A thirty-two way receptacle at shell size 22 is a high-count signal and control interface, used where a single enclosure penetration has to carry an entire instrumentation or control loom rather than a handful of circuits. Box-mounting receptacles suit junction boxes, control enclosures and equipment cases where the internal wiring is terminated after the shell is already fitted to the panel. With this many circuits on one face, contact numbering and harness identification matter as much as the connector selection itself.
Supplied by BOLTON Technical Equipment Supplies against request for quotation. Add this item to your RFQ basket to request pricing, lead time and documentation requirements (e.g. CoC, datasheets or test reports where applicable).
Browse more in Wire & Cable.
