Description
Overview
The YEP 20A HV SBEC is a switch-mode battery eliminator circuit from HobbyKing’s YEP electronics range. It takes the main flight or drive pack as its input and provides a regulated, jumper-selectable low-voltage supply for receivers, servos and other onboard electronics, removing the need for a separate receiver battery. Twin output leads share the load current and provide redundancy, and the regulator carries its own heatsink.
Technical data
- Type: Switching BEC
- Maximum continuous current: 20 A
- Input cells: 2 to 12S lithium / 6 to 35 cells NiMH-NiCd
- Input voltage: 6 to 50 V
- Output voltage: 5 / 5.5 / 6 / 7 / 9 V, jumper-selectable
- Output leads: Dual
- PCB size: 57 x 26 mm
- Weight: 42 g
Applications
Regulated onboard power for receivers and servos in electric and internal-combustion model aircraft and helicopters, from small models up to 800-size helicopters and large petrol-engine aeroplanes.
Sourcing from BOLTON
BOLTON Technical Equipment Supplies sources and supplies YEP 20A HV against request for quotation for defence, aerospace, UAV/UAS, MRO and industrial programmes across the UAE, Saudi Arabia and Australia. Pricing, lead time and documentation requirements (for example certificate of conformity, manufacturer datasheets or test reports where applicable) are confirmed against your RFQ. Add this item to your RFQ basket to request a quotation.
